9590 unstable on Formula-Z

Nepty
Level 9
So I bought 9590 and wont go higher than 4.7GHz... wont even go to turbo on auto..
When clocking the CPU to 4.8-4.9-5.0 the computer freezes up and need to do a hard reset.
This only happen with the 9590 not the 9370 (which i can clock to 4.9GHz).

Is there something wrong with this chip?
I have runned memtest (nothing wrong), reinstalled OS, changed CPU (had no problems there).
The temps are pretty decent because i have pretty good case.
36475

Do I need to RMA this, need a quick answer so I dont end up with a broken CPU.
MOBO | ROG MAXIMUS XII FORMULA
CPU | Intel i9-10850K
COOLER | Corsair iCUE H115i ELITE CAPELLIX's)
RAM | G.Skill Trident Z DDR4 64GB 3200Mhz (3800MHz OC) (F4-3200C14D-32GTZR)
GPU |
ASUS ROG Strix LC RTX 4090 OC
HDD |
Kingston FURY Renegade e M.2 2TB
PSU |
ASUS ROG THOR 1200

CASE |
ASUS ROG Strix Helios White
OS |
Windows 11 Pro 64bit

Monitor |
Asus 48'' 4K PG48UQ x2
12,700 Views
16 REPLIES 16

Detection
Level 10
Have you connected the extra 4 PIN CPU power lead ?
MOBO - Crosshair V Formula
CPU - AMD FX-8350 @ 4.8GHz
COOLER - Corsair H100i / MX-4
RAM - 12GB G.Skill RIPJAWS X @ 2133MHz
GPU - XFX R9 295X2 8GB
HDD - 2TB Seagate
PSU - Corsair TX950W
CASE - Coolermaster HAF 922
OS - Windows 8.1 Pro 64bit

Nepty
Level 9
Yes, otherwise I would have issues with the 8120 and 9370.
MOBO | ROG MAXIMUS XII FORMULA
CPU | Intel i9-10850K
COOLER | Corsair iCUE H115i ELITE CAPELLIX's)
RAM | G.Skill Trident Z DDR4 64GB 3200Mhz (3800MHz OC) (F4-3200C14D-32GTZR)
GPU |
ASUS ROG Strix LC RTX 4090 OC
HDD |
Kingston FURY Renegade e M.2 2TB
PSU |
ASUS ROG THOR 1200

CASE |
ASUS ROG Strix Helios White
OS |
Windows 11 Pro 64bit

Monitor |
Asus 48'' 4K PG48UQ x2

Nepty wrote:
Yes, otherwise I would have issues with the 8120 and 9370.


Not necessarily - I ran the 8350 @ 4.8GHz using just the 8 PIN
MOBO - Crosshair V Formula
CPU - AMD FX-8350 @ 4.8GHz
COOLER - Corsair H100i / MX-4
RAM - 12GB G.Skill RIPJAWS X @ 2133MHz
GPU - XFX R9 295X2 8GB
HDD - 2TB Seagate
PSU - Corsair TX950W
CASE - Coolermaster HAF 922
OS - Windows 8.1 Pro 64bit

MeanMachine
Level 13
I had the same problem when I updated my BIOS. I changed my settings back to default and used the step-up function, one step at a time.

Took the values and went from there, Stable at 5.2GHz but 5.5GHz and you need to monitor temps carefully.
We owe our existence to the scum of the earth, Cyanobacteria

My System Specs:

MB:ASUS ROG Crosshair VII Hero/WiFi GPU:EVGA GTX 1080 sc PSU:Corsair AX-1200i
CPU:
AMD R7 2700X Cooler: Corsair Hydro H115i Case: Corsair Carbide 780t

Memory:G.Skill TridentZ F4-3200C14D-16GTZR SSD:Samsung 500GB 960 EVO M.2


[/HR]

I have done the same thing... but when the turbo wont even kick in when everything is at default/auto then there isnt any tweaking that would improve stability.. Tried almost everything, BIOS OC and still wont work properly.
MOBO | ROG MAXIMUS XII FORMULA
CPU | Intel i9-10850K
COOLER | Corsair iCUE H115i ELITE CAPELLIX's)
RAM | G.Skill Trident Z DDR4 64GB 3200Mhz (3800MHz OC) (F4-3200C14D-32GTZR)
GPU |
ASUS ROG Strix LC RTX 4090 OC
HDD |
Kingston FURY Renegade e M.2 2TB
PSU |
ASUS ROG THOR 1200

CASE |
ASUS ROG Strix Helios White
OS |
Windows 11 Pro 64bit

Monitor |
Asus 48'' 4K PG48UQ x2

From DIGI +VRM there is an option called cpu over current protection just adjust it to 140% it will extend the OC range and gives the cpu more
power

zork wrote:
From DIGI +VRM there is an option called cpu over current protection just adjust it to 140% it will extend the OC range and gives the cpu more
power


Agreed and important, Forgot to mention that! Took me quite a few reboots too to get it right.
We owe our existence to the scum of the earth, Cyanobacteria

My System Specs:

MB:ASUS ROG Crosshair VII Hero/WiFi GPU:EVGA GTX 1080 sc PSU:Corsair AX-1200i
CPU:
AMD R7 2700X Cooler: Corsair Hydro H115i Case: Corsair Carbide 780t

Memory:G.Skill TridentZ F4-3200C14D-16GTZR SSD:Samsung 500GB 960 EVO M.2


[/HR]

Nepty
Level 9
Still freezes up and I need to do a hard reset.
MOBO | ROG MAXIMUS XII FORMULA
CPU | Intel i9-10850K
COOLER | Corsair iCUE H115i ELITE CAPELLIX's)
RAM | G.Skill Trident Z DDR4 64GB 3200Mhz (3800MHz OC) (F4-3200C14D-32GTZR)
GPU |
ASUS ROG Strix LC RTX 4090 OC
HDD |
Kingston FURY Renegade e M.2 2TB
PSU |
ASUS ROG THOR 1200

CASE |
ASUS ROG Strix Helios White
OS |
Windows 11 Pro 64bit

Monitor |
Asus 48'' 4K PG48UQ x2

chrsplmr
Level 18
Nepty,
Freezes up when ? Doing what ?
